Body & Frame Construction
Frame Keel: 40*80*2.5mm keel with 40*60*2.0mm flat frame
Cargo Box Size: 1.8*1.3m, 310mm high with 1.0mm checkered floor
Cargo Box Features: Front and side guardrails, double-layer foldable backrest, large toolbox
Rear Axle: Inner-Floating, Small Booster, 10:35 ratio with φ180 drum
Steel Spring Plate: 4+2 leaf springs (built-in) with coil spring
Front Shock Absorber: φ50, 780mm height with steering stem locknut
Tire: 5.00-12, interchangeable front/rear with spare tire
Additional Features
Battery: 12V9Ah Maintenance-Free dry battery
Brake System: Front Hand / Rear Foot with φ130 mechanical brake
Fuel Tank: Wuyang classic style with recessed mouth
Dashboard: With gear indicator, 12V
Lighting: Round headlight, drill-hole type turn signals, three-round taillights
Air Filter: Suzuki square type with intake port
Carburetor: PZ27 type
Muffler: Black high-temperature paint, round cylinder type
Handlebar Switch: With hazard light switch
Horn: Dual front horns
Forced Fan: Included
Packaging & Shipping
Package: CKD (Complete Knock Down) - upgraded 2024 packaging standard
Quantity per 40HQ Container: 50 pieces
Special Equipment: Standard tool kit, tire removal tool M22, mechanical jack, English manual
Frequently Asked Questions
How to Choose the Right Tricycle
Selecting a proper tricycle requires prioritizing quality and durability over initial cost. Key factors include load capability, fuel consumption, component weight, supplier reliability, and parts interchangeability.
Tricycle Types & Classifications
Tricycles are categorized by engine displacement (150cc to 1000cc), cabin type (none, semi, full), application (cargo, passenger, ATV), and tire configuration (three or five tires).
Critical Performance Components
- Engine: Primary power source from reliable manufacturers
- Carburetor: Critical for fuel efficiency
- Frame/Chassis: Foundation platform requiring manufacturing capability
- Rear Axle & Reverse Mechanism: Bears main vehicle pressure
- Front Shock Absorber: Ensures smooth ride and bump reduction
- Tire: Essential for tough road conditions
- Battery: Affects starting performance
- Electrical Components: Key to electric system safety
Air-Cooled vs Water-Cooled Engines
Water-cooling provides better heat dissipation through internal circulation, making it more effective in hot climates, though it comes at a higher price point than air-cooled systems.
Cargo Carriage Considerations
Proper cargo box size is essential - oversized carriages can cause front-end tilting, engine strain, and reduced passability. Manufacturers typically recommend optimal sizes during design.
Real vs Fake Texture in Cargo Floors
Real texture adds extra steel and weight for increased durability and load capacity, while fake texture creates surface patterns without additional material through embossing from underneath.
Rear Axle Types: Full-Floating vs Semi-Floating
Full-floating axles transmit torque only without bearing vehicle weight, offering higher reliability and easier maintenance. Semi-floating axles bear both torque and weight forces, making them more prone to breakage but less expensive.
Booster Mechanisms
Boosters are gear sets added to rear axle hubs to increase torque and climbing ability. Options include no booster, small booster, and big booster with corresponding price differences.
Manufacturing Note:
Chongqing, China is renowned for stable quality tricycle manufacturing, alongside other production bases in Henan, Hebei, Guangdong, and Jiangsu provinces.
